Large Dumper Driven By Hydrostatic Transmission Pump Has High Cost Performance

Mobile crusher hydrostatic transmission guarantee the high reliability of the product

Quick Detail:

· Cast iron housing

· Hydraulic components

· Model HPV130+HMF130

· Hydraulic system power components

· Principle hydraulic transmission

· Loading method manual loading

· Simple layout

· System Solutions

· Work fast

· Fully replace imported products

· Patent certificate certification

· Application mobile crusher hydrostatic transmission

· 1 year warranty

Description:

Mobile crusher hydrostatic transmission pump features:

Variable Displacement Pumps are well engineered and easy to handle.

Bearings of Variable Axial Piston Pumps are all tapered roller bearing, which can load heavy external axial forces.

Hydraulic pumps can be connected with other additional pumps.

When Hydraulic pumps operated mechanically, the Servo displacement can control and keep the angle of swash plate and pump displacement.

Upon release of the control handle, swash plate return to zero position automatically and the flow reduces to zero.

Hydraulic pumps has shaft oil seals performance, even at the lowest temperature and high case pressure.

Servo valve of piston pump can connect function regulators and remote control systems.

Axial piston pumps can easy maintain and can be disassembled and assembled by standard tools. All components are replaceable.

Specifications:

HPV+HMF Series Technical parameter

Notices:

Hydraulic oil

The suitable replacement period for hydraulic oil in a sealed tank system is 2000 hours, and more often if the hydraulic oil is contaminated with water or other external materials or subjected to abnormal operating conditions.

As a general recommendation, the 10µ inlet oil filter should be replaced every spring or every 1500 hours (whichever occurs first) on a sealed tank system, or in an open tank system with an air filter fill cap. The oil filter should be replaced every 500 hours.

Heat Exchanger

The heat exchanger core and fins are kept clean at all times for maximum cooling and system efficiency, and the exterior of the heat exchanger is checked daily for blockages and cleaned as needed.

Application:

Mixer truck: concrete mixer truck, cement mixer truck;

Coal mining machinery: scraper;

Industry: pharmaceutical machinery;

Transport vehicles: road rollers, concrete pump trucks, stabilized soil mixers

FAQ:

Q1. Can I have a sample order for mobile crusher hydrostatic transmission ?

A: Yes, we welcome sample order to test and check quality.

Q2. What about the lead time?

10 to 15 days for samples, mass production according to MOQ

Q3. Do you have any MOQ limit for mobile crusher hydrostatic transmission ?

A: Low MOQ, 1pc for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

Ship by sea, it generally takes 15-20 days to arrive, and air is also optional.

Q5. How to proceed an order for mobile crusher hydrostatic transmission ?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms the samples and places deposit for formal order.

Fourthly We arrange the production.

Q6: Do you offer guarantee for the products?

A: Yes, we offer 1 years warranty to our products.

Q7: How to deal with the faulty?

Firstly, our products are produced in strict quality control system.Secondly, we will inspect the defective pump and motor, and then respond according to the actual situation.
